タイプ |
ØD(mm) |
Tol. |
Ød(mm) |
Tol.
|
TKØ(mm)
|
Tol.
|
a
|
RRM 0420-3100U2S |
4.0 |
+0.30~+0.50 |
0.80 |
±0.10 |
1.8 |
-0.15 |
0.10 |
RRM 0520-3100U2S |
5.0 |
+0.30~+0.50 |
0.80 |
±0.10 |
2.0 |
-0.15 |
0.13 |
RRM 0630-3100U2S |
6.0 |
+0.30~+0.50 |
1.00 |
±0.15 |
3.0 |
-0.20 |
0.15 |
RRM 0730-3100U2S |
7.0 |
+0.30~+0.60 |
1.00 |
±0.15 |
3.5 |
-0.20 |
0.15 |
RRM 0830-3100U2S |
8.0 |
+0.30~+0.60 |
1.00 |
±0.15 |
4.0 |
-0.30 |
0.15 |
RRM 0930-3100U2S |
9.0 |
+0.30~+0.60 |
1.40 |
±0.15 |
4.0 |
-0.30 |
0.20 |
RRM 1030-3100U2S |
10.0 |
+0.30~+0.60 |
1.40 |
±0.15 |
5.0 |
-0.30 |
0.20 |
RRM 1130-3100U2S |
11.0 |
+0.30~+0.60 |
1.40 |
±0.15 |
5.0 |
-0.30 |
0.28 |
RRM 1230-3100U2S |
12.0 |
+0.30~+0.60 |
1.75 |
±0.15 |
6.0 |
-0.30 |
0.30 |
RRM 1330-3100U2S |
13.0 |
+0.30~+0.70 |
1.75 |
±0.15 |
6.0 |
-0.30 |
0.34 |
RRM 1430-3100U2S |
14.0 |
+0.30~+0.70 |
1.75 |
±0.15 |
7.0 |
-0.30 |
0.37 |
RRM 1530-3100U2S |
15.0 |
+0.30~+0.70 |
2.00 |
±0.20 |
7.0 |
-0.30 |
0.40 |
RRM 1630-3100U2S |
16.0 |
+0.30~+0.70 |
2.00 |
±0.20 |
8.0 |
-0.30 |
0.40 |
RRM 1730-3100U2S |
17.0 |
+0.30~+0.80 |
2.00 |
±0.20 |
8.0 |
-0.30 |
0.47 |
RRM 1830-3100U2S |
18.0 |
+0.30~+0.80 |
2.00 |
±0.20 |
9.0 |
-0.30 |
0.50 |
RRM 1930-3100U2S |
19.0 |
+0.30~+0.80 |
2.00 |
±0.20 |
9.0 |
-0.30 |
0.50 |
RRM 2040-3100U2S |
20.0 |
+0.30~+0.80 |
2.50 |
±0.25 |
10.0 |
-0.40 |
0.50 |
RRM 2140-3100U2S |
21.0 |
+0.30~+0.80 |
2.50 |
±0.25 |
10.0 |
-0.40 |
0.50 |
RRM 2240-3100U2S |
22.0 |
+0.30~+0.80 |
2.50 |
±0.25 |
11.0 |
-0.40 |
0.50 |
RRM 2340-3100U2S |
23.0 |
+0.30~+0.80 |
2.50 |
±0.25 |
11.0 |
-0.40 |
0.50 |
RRM 2440-3100U2S |
24.0 |
+0.30~+0.80 |
3.00 |
±0.25 |
120 |
-0.50 |
0.50 |
RRM 2540-3100U2S |
25.0 |
+0.30~+0.80 |
3.00 |
±0.25 |
12.0 |
-0.50 |
0.50 |
RRM 2640-3100U2S |
26.0 |
+0.30~+0.80 |
3.00 |
±0.25 |
13.0 |
-0.50 |
0.50 |
RRM 2840-3100U2S |
28.0 |
+0.30~+0.80 |
3.00 |
±0.25 |
14.0 |
-0.50 |
0.50 |
RRM 3040-3100U2S |
30.0 |
+0.30~+0.80 |
3.00 |
±0.25 |
14.0 |
-0.50 |
0.50 |
RRM 3240-3100U2S |
32.0 |
+0.30~+0.80 |
3.00 |
±0.25 |
14.0 |
-0.50 |
0.50 |
RRM 3440-3100U2S |
34.0 |
+0.30~+0.80 |
3.00 |
±0.25 |
14.0 |
-0.50 |
0.50 |
|
