Sont Fixés Mécaniquement Inserts-Type CH
Type |
Dimension(mm) |
Poids unitaire environ(g) |
||||||||
d |
s |
H |
r |
a≈ |
d1 |
YG6 |
YG8 |
YT5 |
YT14 |
|
C1305H |
13.0 |
4.5 |
13.0 |
0.5 |
4.5 |
5.2 |
10.9 |
10.6 |
9.4 |
8.3 |
C1305HL |
||||||||||
C1610H |
16.0 |
5.5 |
16.0 |
1.0 |
5.3 |
6.2 |
17.8 |
17.5 |
15.7 |
13.5 |
C1610HL |
||||||||||
C1910H |
19.0 |
7.0 |
19.0 |
1.0 |
6.0 |
7.2 |
32.5 |
32.5 |
27.4 |
24.3 |
C1910HL |
